PC290 kit with monobloc or adjustable boom

You are here: Fumotec » Models » Komatsu PC290-11

PC 290LC-11

PC290 kit with 5 way valve block

Item number: 2900

The scope of delivery includes all components required for construction (hydraulics, drives, etc., see the Kit Contents gallery), as well as two hydraulic add-on connections on the stick incl. control valves and a bucket.

5.543,80 € ()

   Incl. 19 % VAT plus shipping

Cannot be delivered to the following countries:

delivery in 3-6 week

Für später merken

The PC290-11 with adjustable boom can be found at the bottom of this page.

INFO: In the tabsNEEDED ACCESSORIESand MODEL ACCESSORIESbelow, you will find all the necessary parts for building and expanding your personal dream model. After the desired transfer to the shopping cart, you can return to the respective store area via CONTINUE SHOPPING.

The model shown is an example and may include optional special accessories. The basic kit is supplied unpainted and not assembled.

The PC290LC-11 with monoblock boom is a consistent further development of our FUMOTEC model range. It combines all experiences and further developments of the previously known kits. We have incorporated many suggestions from our customers into the design of the model.

In its original form, the PC290LC-11 is a hydraulic excavator in the particularly common class up to 30 tons operating weight. As a functional model, however, this size class has been missing on the construction sites of model builders until now.

What makes this kit typical for FUMOTEC is the solid construction of the undercarriage made of welded steel parts. This ensures an ideal center of gravity with maximum digging performance. The construction is completely based on the drawings and documents of the original.

Another highlight is the removable side panels in the track drive area. This design feature allows the drive assemblies and their controllers to be accessed quickly and without tools at any time.

The particularly detailed superstructure of the upper carriage is produced completely ready for assembly using 3D printing technology and fitted with precisely fitting guide pins. Parts of the fairing are fixed with magnets.

The hydraulics have also been further optimized. The tank is flanged directly to the pump. This minimizes the amount of hosing required in the model during assembly. The complete hydraulic components are specially matched to each other. This results in optimum sensitivity and performance of the model. The PC290LC-11 with monoblock boom is delivered with a 5-fold valve block.

Technical data:

-Height to top of cabin:220mm

-Length of track drive: 345mm

-Width of track drive: 235mm

-Weight: 12 kg

-Scale 1:14,5

-Pump with delivery volume of 700ml/min matched to the model for precise but direct control

All specifications are approximate. Subject to technical changes

-14mm cylinder with 12mm piston optimally adapted to the model for maximum digging performance

Accessories required for operation:

5 pieces servos for hydraulic valve (e.g. Hitec HS-81 or similar)

1 piece of controller for slewing drive (recommended Servonaut MFX)

1 piece controller for hydraulic pump (e.g. Roxxy 722 or similar)

2 pieces of controller for traction drive (e.g. Roxxy 725 4D or similar)

Receiver with at least 9 channels

Battery Lipo 3S 5000 mAh

0,5 liter hydraulic oil (Fumotec order no. 15/2)

Hydraulic seal fluid (Fumotec order no. 15/20)

no products were found that match your selection criteria.

* All prices plus VAT plus shipping

no products were found that match your selection criteria.

* All prices plus VAT plus shipping

Kit contents (subject to technical changes)

Your Fumotec model should be ready for immediate use or a Fumotec model kit should be shipped to you already painted?

We now offer three attractive service offers that support the desire for a finished and ready-to-use model from the very beginning. With our service you get once more the possibility to realize your dream model with Fumotec. We are presenting an attractive offer with a unique variety of models for every taste. Orders for construction and painting services are individual custom-made products and therefore excluded from revocation and exchange!

  • Building service PC290

    You don't have the time or the desire to build? You want to get your model ready for another reason? We build your Fumotec dream model ready for use for you!

    1.498,20 €*

    Für später merken

  • Painting service PC290 Basic

    The Basic painting service includes painting with high-quality 2-component uni paints in Komatsu design. The cab is not painted on the inside and may have paint mist, the quick coupler is painted in the gray tone of the Untrerwagen. The Basic paint is our low-cost alternative. Our goal is to color the parts with a high quality paint and the practiced hand of the professional for a fair price. Visible parts are sanded before painting. Components that are not in the visible area may have a slight surface texture.

    1.391,20 €*

    Für später merken

  • Painting service PC290 exclusive

    Painting service PC290 Exclusive - the name of this offer stands for itself. With this high-end painting, the corresponding components are provided with an elaborate multi-layer paint job. A lot of effort is put into the type designation as well as the original manufacturer's lettering of the model: These are painted with much attention to detail in this service!

    1.724,10 €*

    Für später merken

no products were found that match your selection criteria.

* All prices plus VAT plus shipping

PC290 kit with adjustable boom

Item number: 2910

The scope of delivery includes all components required for construction (hydraulics, drives, etc., see the Kit Contents gallery), as well as two hydraulic add-on connections on the stick incl. control valves and a bucket.

6.242,40 € ()

   Incl. 19 % VAT plus shipping

Cannot be delivered to the following countries:

delivery in 3-6 week

Für später merken

The model shown is an example and may include optional special accessories. The basic kit is supplied unpainted and not assembled.

The PC290-11 with adjustable boom complements the Fumotec PC290 with monoblock boom in our model range. In the version with adjustable boom, the excavator becomes even more flexible to use, which further increases the play value of this model. The PC290-11 with adjustable boom is delivered with a 6-valve block. All other features correspond to the version with 5-fold valve block.

Technical data:

-Height to top of cabin:220mm

-Length of track drive: 345mm

-Width of track drive: 235mm

-Weight: 12 kg

-Scale 1:14,5

-Pump with delivery volume of 700ml/min matched to the model for precise but direct control

All specifications are approximate. Subject to technical changes

-14mm cylinder with 12mm piston optimally adapted to the model for maximum digging performance

Accessories required for operation:

6 pieces servos for hydraulic valve (e.g. Hitec HS-81 or similar).

1 piece controller for slew drive (recommended Servonaut MFX)

1 piece controller for hydraulic pump (e.g. Roxxy 722 or similar)

2 pieces of controller for traction drive (e.g. Roxxy 725 4D or similar)

Receiver with at least 9 channels

Battery Lipo 3S 5000 mAh

0,5 liter hydraulic oil (Fumotec order no. 15/2)

Hydraulic seal fluid (Fumotec order no. 15/20)

no products were found that match your selection criteria.

* All prices plus VAT plus shipping

no products were found that match your selection criteria.

* All prices plus VAT plus shipping

Kit components

Do you want your Fumotec model to be ready for immediate use or a Fumotec model kit to be sent to you already painted?

You don't have the time or desire to build? Would you like to have your model delivered ready for use for another reason? We are now offering three attractive service packages to support your desire for a finished and ready-to-use model right from the start. Our service once again gives you the opportunity to realize your dream model with Fumotec. A unique variety of models for every taste is now even more attractive! Orders for building and painting services can only be realized in conjunction with the purchase of a kit. These services are individual custom-made products which cannot be returned or exchanged!

  • Building service PC290

    You don't have the time or the desire to build? You want to get your model ready for another reason? We build your Fumotec dream model ready for use for you!

    1.498,20 €*

    Für später merken

  • Painting service PC290 Basic

    The Basic painting service includes painting with high-quality 2-component uni paints in Komatsu design. The cab is not painted on the inside and may have paint mist, the quick coupler is painted in the gray tone of the Untrerwagen. The Basic paint is our low-cost alternative. Our goal is to color the parts with a high quality paint and the practiced hand of the professional for a fair price. Visible parts are sanded before painting. Components that are not in the visible area may have a slight surface texture.

    1.391,20 €*

    Für später merken

  • Painting service PC290 exclusive

    Painting service PC290 Exclusive - the name of this offer stands for itself. With this high-end painting, the corresponding components are provided with an elaborate multi-layer paint job. A lot of effort is put into the type designation as well as the original manufacturer's lettering of the model: These are painted with much attention to detail in this service!

    1.724,10 €*

    Für später merken

no products were found that match your selection criteria.

* All prices plus VAT plus shipping
